Motor pas cu pas Nema23 76mm 1,9Nm 6.35mm

172,68 Lei

(145,11 Lei + 19% TVA)

Timp de livrare:

2-4 zile lucrătoare

Descriere

Specification:
Model: 23HS8430
Type: Hybridschrittmotor
No. of phase:2
Shaft Diameter:6,35mm
Motor Length:76mm
Step Angle ( °):1,8
Rated Voltage(V):2,7
Rated Current (A):3,0
Phase Resistance (Ω):0,9
Phase Inductance (mH):3,8
Holding Torque (N.m):1,9
Detent Torque (N.cm Max):6,5
Rotor Torque (g.c㎡):450
Lead Wires (NO.):4
Motor Weight (g): 1030

Info produs

Masa:

1030 g/bucăți
